Honda BF5DH SCHU - 5 HP, 4-stroke outboard motor short transom
lei7,550.00
Tax included
1-3 days
The Honda BF2.3DH SCHU is a lightweight, portable, 2.3 horsepower, 4-stroke outboard motor known for its reliability and quiet operation. It's designed for small boats, canoes, and inflatables, and features an air-cooled engine and a centrifugal clutch. The "SCHU" designation indicates a short shaft and manual recoil start.
Key Features:
Lightweight and Portable: It is one of the lightest four-stroke outboards, making it easy to transport and mount on various small vessels.
4-Stroke OHV Engine: Features a single-cylinder, overhead valve (OHV) engine with 2 valves.
Air-Cooled: The engine is air-cooled, eliminating the need for a water pump and simplifying maintenance.
Centrifugal Clutch: Provides smooth engagement and disengagement of the propeller.
360-degree Steering: Allows for easy maneuverability.
Short Shaft (SCHU): Designed for boats with a transom height that requires a shorter shaft length.
Manual Recoil Start: Starts with a pull cord.
Fuel Efficient: Features a larger internal fuel tank for extended run time.
Reliable and Quiet: Known for its quiet operation and dependable performance.
Advanced Corrosion Protection: Includes features to resist corrosion, enhancing longevity.
Applications:
The Honda BF2.3DH SCHU is ideal for:
Small boats, dinghies, and tenders.
Inflatable boats.
Auxiliary power for larger boats.
Fishing boats.
Recreational boating on calm waters.
Specifications:
Displacement: 57.2 cc (3.49 cubic inches)
Bore and Stroke: 45 mm x 36 mm (1.8 x 1.4 inches)
Full Throttle RPM Range: 5,000-6,000 RPM
Rated Power: 2.3 horsepower (1.7 kW)
Fuel Type: Unleaded gasoline (86 octane or higher)
Fuel Tank Capacity: .29 US gallons (1.1 liters)
Oil Capacity: 0.25 L (0.22 Imp. qt)
Weight: Approximately 27 lbs (13.5 kg)
Gear Ratio: 2.42:1
Trim Range: 4-stage (5°, 10°, 15°, 20°)
Tilt Range: 75°
TRansom height (L) 571 mm / 22.5 in
BF5DH SCHU
Data sheet
- Engine type
- Petrol 4 stroke
- Start type
- Manual
- Warranty
- 24 luni persoane fizice/ 12 luni persoane juridice
- Power
- 5 HP
- Transom height
- Short
- Alternator
- Yes
